| Why you choose us? | |||
| 1. more than 20 years experiences in steel business | |||
| 2. good quality | |||
| 3. competitive price | |||
| 4. meet your needs via reprocessing | |||
| 5. excellent service | |||
| 6. short delivery time | |||
| 7. long mutual beneficial business cooperation |
|
Diameter |
10mm~914.4mm |
|
Schedule |
sch10~schxxs |
|
Thickness |
1mm~100mm |
|
Unit length |
3m, 5.8m, 6m, 11.8m, 12m, 13.5m or as per customers' request |
|
Brand |
TPCO,BAOSTEEL,BAOTOU STEEL,TIANDA,LONTRIN,HYST etc. |
|
Standard |
ASTM A106,A53,A179,A192,A333,A519,A795,A335,A500 API 5L, API 5CT JIS G3452,G3454,G3455,G3456,G3444,G3460,G3461,G3464 DIN1629,DIN2391 EN10210,EN10025 GB/T 8163, GB/T 5310,GB/T 3087and so on |
|
Material |
A,B,C,Gr.3,Gr.6 P5,P9,P11,P12,P91... PSL1/PSL2 X42,X52,X60,X65,X70,X80 SGP,STPG,STS,STPT,STPL,STB,STBL ST35,ST37,ST52 S235,S275,S355 Q235,Q345,10#,20#,45#,16Mn and so on |
|
Surface |
Cold Drawn, Cold Rolled, Welded |
|
Packing |
in bundles, in loose, plastic end caps or end protectors,non-woven fabrics packings |
|
Application |
conveying oil,steam,water,gas,air at low/medium/high pressure or temperature fire protection systems civil engineering, architecture and other structures shipyard,oil field,gas field |
|
Steel pipe size
|
A
|
DN15
|
20
|
25
|
32
|
40
|
50
|
65
|
80
|
|
B
|
1/2''
|
3/4"
|
1''
|
1.1/4''
|
1.1/2''
|
2''
|
2.1/2''
|
3''
|
|
|
outer diameter
|
ASME
|
21.3
|
26.7
|
33.4
|
42.2
|
48.3
|
60.3
|
73
|
88.9
|
|
wall thickness
|
SCH10
|
2.11
|
2.11
|
2.77
|
2.77
|
2.77
|
2.77
|
3.05
|
3.05
|
|
SCH30
|
2.41
|
2.41
|
2.9
|
2.97
|
3.18
|
3.18
|
4.78
|
4.78
|
|
|
STD
|
2.77
|
2.87
|
3.38
|
3.56
|
3.68
|
3.91
|
5.16
|
5.49
|
|
|
SCH40
|
2.77
|
2.87
|
3.38
|
3.56
|
3.68
|
3.91
|
5.16
|
5.49
|
|
|
XS
|
3.73
|
3.91
|
4.55
|
4.85
|
5.08
|
5.54
|
7.01
|
7.62
|
|
|
SCH80
|
3.73
|
3.91
|
4.55
|
4.85
|
5.08
|
5.54
|
7.01
|
7.62
|
|
|
SCH160
|
4.87
|
5.56
|
6.35
|
6.35
|
7.14
|
8.74
|
9.53
|
11.13
|
|
|
XXS
|
7.47
|
7.82
|
9.09
|
9.7
|
10.15
|
11.07
|
14.02
|
15.25
|
Seamless Steel Pipe Package and Delivery
Package:
Packing Details: Bundle with steel strip, shipped in wooden cases or wooden pallets
Delivery Details: Use trays to facilitate loading and unloading
Standard Export Seaworthy Package.
Or Package can also according to your requirements
Leading Time:
Within 7-10 days after receipt of advance payment
