Standard |
API A106 GR.B A53 Gr.B seamless steel pipe / ASTM A106 Gr.B A53 Gr.B steel tube AP175-79, DIN2I5L , ASTM A106 Gr.B, ASTM A53 Gr.B, ASTM A179/A192/A213/A210 /370 WP91, WP11,WP22. DIN17440, DIN2448,JISG3452-54. |
|
Material |
API5L,Gr.A&B, X42, X46, X52, X56, X60, X65, X70, X80, ASTM A53Gr.A&B,ASTM A106 Gr.A&B, ASTM A135, ASTM A252, ASTM A500, DIN1626, ISO559, ISO3183.1/2, KS4602, GB/T911.1/2,SY/T5037, SY/T5040 STP410,STP42. |
|
Certificates |
API5L ISO 9001:2008 TUV SGS BV etc |
|
Outside Diameter |
1/2'--24' |
|
21.3mm-609.6mm |
|
|
Thickness |
SCH5S, SCH10S, SCH20S,SCH20, SCH30,STD, SCH40, SCH60, SCH80, SCH100, SCH140, SCH160,XS, |
|
1.65mm-59.54mm |
|
|
Length |
5.8m 6m Fixed, 12m Fixed, 2-12m Random. |
|
Technic |
1/2'--6': hot piercing processing technic |
|
6'--24' : hot extrusion processing technic |
|
|
Surface Treatment |
Black Painted, Galvanized, Natural, Anticorrosive 3PE coated,polyurethane foam Insulation . |
|
Packing |
Bundles or In bulk. bundled pipes with two slings at the both end for easy loading and discharging, |
|
End |
Bevel end(>2"), Plain (≤2"),with plastic cap, with screwed and socket. |
|
Usage /Application |
Oil pipe line, Drill pipe, Hydraulic pipe, Gas pipe, Fluid pipe, Boiler pipe,Conduit pipe, Scaffolding pipe pharmaceutical and ship building etc. |
| TYPE | Steel grade | C . | Si | Mn . | P | S |
| API 5L PSL1 | B | ≤0.28 | - | ≤1.20 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X42 | ≤0.28 | - | ≤1.3 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X52 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X56 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X60 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X65 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| API 5L PSL1 | X70 | ≤0.28 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| TYPE | grade | Tensile strength (Mpa) |
Yield strength (Mpa) |
Elongation |
| API 5L PSL1 | B | ≥415 | ≥245 | As per API 5L |
| API 5L PSL1 | X42 | ≥415 | ≥290 | As per API 5L |
| API 5L PSL1 | X52 | ≥460 | ≥360 | As per API 5L |
| API 5L PSL1 | X56 | ≥490 | ≥390 | As per API 5L |
| API 5L PSL1 | X60 | ≥520 | ≥415 | As per API 5L |
| API 5L PSL1 | X65 | ≥535 | ≥450 | As per API 5L |
| API 5L PSL1 | X70 | ≥565 | ≥483 | As per API 5L |
| Level | Steel grade | C . | Si | Mn . | P | S |
| PSL2 | B | ≤0.24 | - | ≤1.20 | ≤0.03 | ≤0.03 |
| PSL2 | X42 | ≤0.24 | - | ≤1.3 | ≤0.03 | ≤0.03 |
| PSL2 | X52 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X56 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X60 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X65 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| PSL2 | X70 | ≤0.24 | - | ≤1.4 | ≤0.03 | ≤0.03 |
| Level | grade | Tensile strength (Mpa) |
Yield strength (Mpa) |
Elongation |
| PSL2 | B | 415-760 | 245-450 | As per API 5L |
| PSL2 | X42 | 415-760 | 290-495 | As per API 5L |
| PSL2 | X52 | 460-760 | 360-530 | As per API 5L |
| PSL2 | X56 | 490-760 | 390-545 | As per API 5L |
| PSL2 | X60 | 520-760 | 415-565 | As per API 5L |
| PSL2 | X65 | 535-760 | 450-600 | As per API 5L |
| PSL2 | X70 | 565-758 | 483-621 | As per API 5L |
Packing details:
1.Black varnish painted or oil painted anti-corrosion oil ,2PE, 3PE on the surface
2.Plain,squire cut or bevelled end by caps
3.In hexagon or triangle bundle with steel strips
4. Marking: As per customer's requirment
Shipping details:
Trade Terms:FOB/CIF/CFR
Payment Terms:L/C,T/T, Western Union.
Loading Port:XinGang TianJin, China
Delivery: Within 15-20days after we receive deposit or L/C at sight
Application
Low and middle pressure fluid pipeline, boiler, petroleum and natural gas industry, drilling, chemical industry, electric industry, shipbuilding, fertilizer equipment and pipeline, structure, petrochemical, pharmaceutical industry
Surface
Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE, etc.
Certificate
ISO9001: 2008, SGS, BV, etc
Capacity
50000tons/year
Advantages
1. Reasonable price with excellent quality
2. Abundant stock and prompt delivery
3. Rich supply and export experience, sincere service
4. Reliable forwarder, 2-hour away from port.
We special in manufacturing the steel pipe and steel pipe fittings
30+years of pipe and fittings production experience at your services
