Standard
|
AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
|
|
Material
|
201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321, 310S, 309S, 410, 410S,420, 430, 431, 440A, 904L, 2205, 2507, ect.
|
|
Out- Diameter
|
Seamless Pipe: 6mm-530mm
Welded Pipe: 8mm-3000mm |
|
|
Seamless Pipe: 1.0mm - 40mm
Welded Pipe: 0.5mm-45mm As Your Request |
|
Tolerance
|
a) Outer Diameter: +/-0.2mm
b) Thickness: +/- 1% or as customer request
c) Length: +/- 10mm |
|
Length
|
1-12m or as Your Request
|
|
Surface
|
2B,BA(bright annealed) NO.1 NO.2 NO.3 NO.4,2D, 4K, 6K, 8K HL(Hair Line), SB, Embossed,as your request
|
|
Certificate
|
BV,ISO ,CE,SGS,TUV
|
|
Seaworthy Packaging
|
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM
|
|
0ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM
|
| Surface | Description |
| Plug Draw | The surface roughness is improved by precise cold drawing of the plug, which can improve the surface structure |
| Mechanically Polished | Surface roughness enhanced by precision grinding |
| Pickled & Passivated | Pickled or passivated to remove particles remaining on the surface |
| Buffed Polished | use polishing paste to improve surface brightness, often used in decoration industry |
| Bright Annealing | Use high temperature heat treatment in a vacuum state to form a passivation film on the surface |
| Anodical Cleaning | On the basis of BA, add a mild electrolytic polishing process and thicken the passivation film |
| Electro-Polished | Through electrochemical polishing, the surface has a closed and thick chromium oxide film |
| Tube for machining structure | |||||
| Variety classification | measure | Steel grade/brand | executive standard | application area | |
| Outside-Diameter (mm) | Wall-Thickness (mm) | ||||
| Structural pipe | 42~760 | 4~120 | 20#, 35#, 45#, Q345A/B/C/D, Q390, Q420, 25Mn, 27SiMn, etc. | GB/T 8162 | General structure with, Mechanical tube |
| Vehicle tube | 45~245 | 4~35 | 20Mn2,SAE1527,MZ410R,MZ530R,30Mn2,40Cr,45Mn2,etc. | YB/T5035, technical protocol |
Tube for automobile axle and automobile axle sleeve |
| Tube for die casting | DN200~DN1200 | 21CrMo10,21CrMo10-2,etc. | Q/OHAD030, technical protocol |
Centrifugal ductile iron pipe Tube die blank |
|
| Military pipe | 42~760 | 4~120 | 30Cr,40Cr,35CrNi1MoA,etc. | Military standards and agreements | Military tube |
| Pipe for geological drilling | 42~133 | 4~25 | DZ40,DZ55,STM-R780,DZ60,etc. | Q/OHAD006, GB/T 9808 , technical protocol |
Drilling pipe |
| Pipe for hydraulic prop | 42~760 | 4~120 | 20#,35#,45#,27SiMn,30MnNbRE,30CrMnSi,30CrMnSiA,etc. | GB/T 17396, technical protocol |
Making hydraulic equipment for coal mining, hydraulic cylinders and plungers for truck cranes. |
| Fluid conveying pipe | 42~760 | 4~120 | 20#,Q345,Q390,etc. | GB/T 8163, technical protocol |
Used as a tube for conveying fluid. |
|
Packing
|
Each tube is wrapped in a plastic sleeve with a cap on the end to ensure the best cleanliness
|
|
OEM accepted, besides,the pakage can also be according to your demands.
|
|
|
Shipping
|
1.Shipping by containers
|
|
2.Shipping by bulk ship.
|
